LST-LRE-1465

1570nm rangefinders module from Lumispot Tech are based on a fully self-developed 1570nm OPO laser, with features of cost-effectiveness and adaptability to a variety of platforms. The main functions include: single-pulse rangefinder, continuous rangefinder, distance selection, front and rear target display, and self-test function.

contact product expert

Product Detail

Product Tags

Product characteristics

Eye-Safe
Lightweight
High Precision
Low-power Consumption
Defense Grade Tempeterature
Resistance to high impact

Specifications

Optical	Parameter	Remarks
Wavelength	1570nm+10nm
Beam angle divergence	1+0.2mrad
Operating range A	300m~27km	Big target
Operating range B	300m~14km	Target size : 2.3x2.3m
Operating range C	300m~7km	Target size : 0.1m²
Rang Accuracy	±5m
Operating frequency	1~10Hz
Voltage supply	DC18-32V
Operating temperature	-40℃~60℃
Storage temperature	-50℃~70°C
Communication interface	RS422
Dimension	214.3mmx116mmx81.15mm
Life-time	≥1000000 times

Note:* Visibility ≥25km, target reflectivity 0.2, divergence Angle 0.6mrad
